Solar Panel 455W Mono Super High Power PERC 144 Cells Silve

$CanadianSolar\CanadianSolar_CS3W455MS.jpg$

Description

Solar Panel, CS3W Model, Mono-Crystalline, 144 Cell, 455 Watt, 41.3 Volt, 11.02 Amp, 49.3 Volt Open Circuit, 11.66 Amp Short Circuit, 20 Amp Max. Fuse Current, 1000/1500 Volt Max. System Voltage, 20.6% Efficiency, 0-5 Watt Power Tolerance, T4-PC-1/PV-KST4/XY-UR, PV-KBT4-EVO2/XY/UTXCFA4AM, UTXCMA4AM Connector, 4 mm (IEC)/12 AWG (UL) Output Cables, IP68/3 with Bypass Diodes Junction Box, Silver Anodized Aluminium Alloy Frame Construction, 3.2 mm Tempered Glass Front Glass, -0.35%/deg C Temperature Coefficient, -40 to 85 deg C, 2108 mm Length, 1048 mm Width, 40 mm Height, 24.9 kg, IEC 61215, IEC 61730:VDE, CE, MCS, INMETRO, UL 1703:CSA

Key Specifications

Brand	Canadian Solar
Range Name	HiKu
Product Type	Solar Panels
Length	2108 mm Show different lengths
SKU	CASCS3W-455MS
Color	Black Show more colours

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	1
UNSPSC Class	26111600
UOM	EA
Vendor Product	CS3W-455MS
Cell Type	Monocrystalline
Frame Construction	Silver Anodized Aluminium Alloy
Model	CS3W
Number Of Cells	144
Power Tolerance	0-5 Watt
Height	40 mm
Width	1048 mm
Connector Type	T4-PC-1/PV-KST4/XY-UR; PV-KBT4-EVO2/XY/UTXCFA4AM; UTXCMA4AM
Certifications	IEC 61215 IEC 61730:VDE CE MCS INMETRO UL 1703:CSA
Efficiency	20.60%
Front Glass	3.2 mm Tempered Glass
Junction Box	IP68/3 with Bypass Diodes
Item Weight	24.9 kg
Max. System Voltage	1000/1500 Volt
Operating Temperature	-40 to 85 deg C
Output Cables	4 sq-mm (IEC)/12 AWG (UL)
Temperature Coefficient	-0.35%/deg C
